Drawings and specifications coordinated well enough to measure, price and trust
A cost plan is only as reliable as the information beneath it. DiagramX is a London Architecture, Engineering and Construction consultancy that issues architecture, structure and MEP as a single coordinated set, so quantity surveyors measure one version of the truth rather than reconciling three.
[ 01 ]
Drawings are dimensioned, scheduled and specified for take-off.

[ 02 ]
Structure and services are checked against the architecture before issue.

[ 03 ]
We discuss cost drivers with you while options are still open.

[ 04 ]
Queries on quantities or scope are resolved directly by the designer.

A cost plan is only as reliable as the information beneath it. We issue architecture, structure and MEP as one coordinated set, so you work from a single version of the information.
Structure and services are checked against the architecture before issue, and builders' work requirements are shown on the drawings. We discuss cost drivers while options are still open, give you a named contact for each discipline, and issue clarifications in writing.
